HARO
HARO - FLIGHTLINE ONE 27.5IN
HARO - FLIGHTLINE ONE 27.5IN
Regular price
$550.00 SGD
Regular price
Sale price
$550.00 SGD
Unit price
/
per
Couldn't load pickup availability
Flightline One
- Year: 2017
- MSRP: $379.99 *
- Sizes: 13", 15", 17", 19", 21"
- Colors: SG Black / Grey / Neon, SG Red / Burgundy
- Weight:
- NO LONGER AVAILABLE
Get a fresh, rambunctious outlook on your neighborhood ride. With versatile 26" wheels and low standover height, the 2017 Flightline One is calling you to explore new trails and kick up some dirt, all with confidence and style.
FEATURES
- Haro FL3G 6000 Series alloy frame
- HL CH-389 26" suspension fork w/ 80mm travel
- 1-1/8" Threadless headset
- Suntour XCC-T102 42/34/24 alloy crankset
- Sealed cartridge BB set
- Shimano Tourney TY-500 front derailleur
- Shimano Tourney TY-300 rear derailleur
- Shimano EF-41 3x7-speed shifters
- Shimano HG-20 7-speed cassette 12-32T
- Pivit alloy 25mm riser bar 31.8mm & melt forged Streem
- DH 18 alloy double wall rims w/ Pivit alloy cassette 32h hubs
| Frame Components | |
|---|---|
| Frame | Haro Flightline FL3 G 6000 Series Alloy |
| Fork | HL CH-389 Fork, 26"w/ 80mm Travel |
| Headset | 1-1/8" Threadless Steel Cups, Loose Ball, Nylon Top |
| Frame Shock | N/A |
| Drivetrain | |
| Cranks | SR Suntour XCC-T102 42/34/24t |
| Bottom Bracket | Sealed Cartridge |
| Chain | KMC Z51, 1/2″ X 3/32 |
| Front Derailleur | Shimano Tourney TY-500 |
| Rear Deralleur | Shimano Tourney TY-300 |
| Derailleur Shifter | Shimano EF-41 3x7-Spd |
| Pedals | FPD Platform, Nylon Body, Crmo Axles |
| Wheels | |
| Tires | H-5120 26x2.10" |
| Wheels/Rims | XD-180 Alloy DW 32h Rims w/ Pivit Alloy Cassette Hubs |
| Freewheel/Cassette | Shimano HG-200 7-Spd Cassette 12-32t |
| Braking System | |
| Brakes | Promax TX-121 V-Brakes |
| Brake Levers | Shimano EF-41 |
| Other Components | |
| Grips | Haro MTB |
| Handle Bar | Pivit Alloy 25mm Riser Bar 31.8mm |
| Stem | Pivit Alloy, 31.8mm |
| Seat | Haro Flightline |
| Seat Post | Pivit Alloy Micro Adjust 30.9mm |
| Seat Clamp | Pivit Alloy 34.9mm Quick Release |
| Size | Head Angle | Seat Angle | Top Tube (Effective) | Seat Tube (C-T) | Chainstay Length | BB Drop | Wheel Base | Stand Over | Stack Height | Reach | Fork Height | Fork Offset | Stem Length | Bar Width | Crank Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 13 | 70.5° | 73° | 553mm (21.8") | 330mm (13") | 425mm (16.7") | 35mm (1.4") | 1026mm (40.4") | 597mm (23.5") | 550mm (21.7") | 385mm (15.2") | |||||
| 15 | 71° | 73° | 571mm (22.5") | 381mm (15") | 425mm (16.7") | 35mm (1.4") | 1039mm (40.9") | 631mm (24.8") | 561mm (22.1") | 400mm (15.7") | |||||
| 17 | 71° | 73° | 595mm (23.4") | 432mm (17") | 425mm (16.7") | 35mm (1.4") | 1063mm (41.9") | 661mm (26") | 571mm (22.5") | 421mm (16.6") | |||||
| 19 | 71° | 73° | 614mm (24.2") | 483mm (19") | 425mm (16.7") | 35mm (1.4") | 1083mm (42.6") | 708mm (27.9") | 580mm (22.8") | 436mm (17.2") | |||||
| 21 | 71° | 72° | 625mm (24.6") | 533mm (21") | 425mm (16.7") | 35mm (1.4") | 1083mm (42.6") | 746mm (29.4") | 590mm (23.2") | 433mm (17") |
